Ref.: 609993 10
Heavy goods trailer 40 t, turntable steering
platform 4.0 x 2.0 m
Platform length [mm]
Ref.: 609993 10
Heavy goods trailer 40 t, turntable steering
platform 4.0 x 2.0 m
platform 4.0 x 2.0 m
Platform length [mm]
on request
Price / item (Ex. VAT)
Availability: 10-12 weeks
Good reasons to purchase products from us
- Worldwide delivery
- Perfect service
- Individual offers
- Fast delivery
We will be happy to help you
export@kaiserkraft.com
Do you have any questions about this product?on request
Price / item (Ex. VAT)
Product description
- Small turning circle – steering radius 45°
- Impregnated wooden platform for weather resistant and non-destructive load support
- Robust welded steel construction
- Low maintenance
- Durable
- In line with workplace safety regulations for transport vehicles
Wheel type
Dual tyres, solid rubber wheels with welded steel rims. Dual roller bearings, DIN compliant. Permanent lubrication, sealed to be dustproof and greaseproof.
Platform
Impregnated pine laminate.
Paintwork
Pure orange RAL 2004.
Dual tyres, solid rubber wheels with welded steel rims. Dual roller bearings, DIN compliant. Permanent lubrication, sealed to be dustproof and greaseproof.
Platform
Impregnated pine laminate.
Paintwork
Pure orange RAL 2004.
On request
Various platform linings, puncture proof solid tyres, parking brake, rubber axle and lead spring, CSE tyres, side walls, weather protection structure, lighting, sheet metal covering, stanchions, compressed air brake, mesh panel, mesh construction and folding aluminium side panels, folding loading ramps, electric brake, special paint finish, support feet, long material trailer, long material trailer with adjustable rear vehicle, special trailer with overrun brake, drawbar height adjustment mechanism, cropped drawbar, fixed bogie, dual action wheel chock with chain and bracket, cranked drawbar with drawbar height adjustment mechanism, low loader, low loader with hand crank parking brake, low loader with weather protection structure and other accessories
Various platform linings, puncture proof solid tyres, parking brake, rubber axle and lead spring, CSE tyres, side walls, weather protection structure, lighting, sheet metal covering, stanchions, compressed air brake, mesh panel, mesh construction and folding aluminium side panels, folding loading ramps, electric brake, special paint finish, support feet, long material trailer, long material trailer with adjustable rear vehicle, special trailer with overrun brake, drawbar height adjustment mechanism, cropped drawbar, fixed bogie, dual action wheel chock with chain and bracket, cranked drawbar with drawbar height adjustment mechanism, low loader, low loader with hand crank parking brake, low loader with weather protection structure and other accessories
The technical specifications for these trailers makes it necessary to manufacture them to order.
For this reason, please be aware that there is no right of return for these items.
For this reason, please be aware that there is no right of return for these items.
Technical data
| Max. load at 6 km/h | 40 t |
|---|---|
| Platform width | 2000 mm |
| Loading height | 950 mm |
| Steering | turntable with pendulum axle |
| Platform material | pine wood covering, treated with preservative |
| Type of tyre | twin tyres |
| Finish | painted |
| Wheel type | solid rubber |
| Wheel width | 320 mm |
| Wheel diameter | 550 mm |
| Colour | pure orange RAL 2004 |
| Product type | industrial trailers |
| Supplied | assembled |
| Platform length | 4000 mm |
| Weight | 2750 kg |
Sustainability
Product with potential for future improvement
This product does not yet meet enough of our sustainability criteria. This does not mean that it has no sustainable properties – however, the total score is lower than 3 points. Therefore, it is not (yet) labelled as particularly sustainable. Our sustainability assessment is based on transparent, clearly defined ecological, social and economic criteria. The aim is to highlight development potential and create greater transparency.
You can find out more about product evaluation and our sustainability initiative on our information page.
This product does not yet meet enough of our sustainability criteria. This does not mean that it has no sustainable properties – however, the total score is lower than 3 points. Therefore, it is not (yet) labelled as particularly sustainable. Our sustainability assessment is based on transparent, clearly defined ecological, social and economic criteria. The aim is to highlight development potential and create greater transparency.
You can find out more about product evaluation and our sustainability initiative on our information page.
