Ref.: 157252 10

Trailer 4-wheel linked ackerman steering, max. load 3 t

Trailer

platform 2.0 x 1.0 m, pneumatic tyres

Platform length [mm]
Platform width [mm]
Loading height [mm]
3.675,00 €
Price / item (Ex. VAT)
Availability: 10-12 weeks
Product description
  • Impregnated wooden platform for weather resistant and non-destructive load support
  • Small turning circle – steering radius 40°
  • Robust welded steel construction
  • Detachable drawbar, trailer coupling on both sides
  • Low maintenance
  • Precision tracking stability
  • Durable
  • Track rods and steering rods with maintenance free ball heads
  • In line with workplace safety regulations for transport vehicles
Chassis
Frame construction with rounded corners. Pipe corners for attaching posts or side panels, or as tie-down eyes. Pine laminate, hard-wearing varnish. Trailer coupling.
Wheel type
Solid rubber or pneumatic tyres. Hubs with double ball bearings.
Paintwork
Pure orange RAL 2004.

All-wheel Ackerman steering, tracking stability. Triangle drawbar, height adjustable with fall arrest.
On request
Parking brake, rubber axle and lead spring, CSE tyres, side walls, weather protection structure, lighting, sheet metal covering, stanchions, compressed air brake, mesh panel, mesh construction and folding aluminium side panels, folding loading ramps, electric brake, special paint finish, support feet, long material trailer, long material trailer with adjustable rear vehicle, special trailer with overrun brake, drawbar height adjustment mechanism, cropped drawbar, fixed bogie, dual action wheel chock with chain and bracket, cranked drawbar with drawbar height adjustment mechanism, low loader, low loader with hand crank parking brake, low loader with weather protection structure and other accessories
The technical specifications for these trailers makes it necessary to manufacture them to order.
For this reason, please be aware that there is no right of return for these items.
Technical data
Max. load at 6 km/h3 t
Steering4-wheel axle knuckle
Platform materialwood coating, treated with preservative
Type of tyresingle tyre
Featuredetachable drawbar
Finishpainted
Colourpure orange RAL 2004
Steering radius40 °
Towing eyelet diameter35 mm
Product typeindustrial trailers
Suppliedassembled
Platform length2000 mm
Platform width1000 mm
Loading height515 mm
Wheel typepneumatic tyres
Wheel width112 mm
Wheel diameter414 mm
Weight267 kg
Manufacturer / EU responsible Person (GPSR)
Sustainability
Product with potential for future improvement

This product does not yet meet enough of our sustainability criteria. This does not mean that it has no sustainable properties – however, the total score is lower than 3 points. Therefore, it is not (yet) labelled as particularly sustainable. Our sustainability assessment is based on transparent, clearly defined ecological, social and economic criteria. The aim is to highlight development potential and create greater transparency.

You can find out more about product evaluation and our sustainability initiative on our information page.

Product CO₂ footprint

LCA functional unit
1
Recycled content in %?
50
CO2 footprint year of calculation
2026
LCA validity (in years)
1
CO2 footprint calculation method product
Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
CO2 footprint system boundaries
Cradle-to-gate

PCF Lifecycle Breakdown

1,095kg CO₂e
LCA Raw Material Extraction & Processing
35.2%
LCA packaging production
1.8%
LCA Product Manufacturing
53.5%
LCA Inbound and Outbound Transportation
9.4%
‌
‌
‌
‌
