Ref.: 762662 10

LKRA-VPA light duty swivel castor – Blickle plate dimensions 57 mm

LKRA-VPA light duty swivel castor – Blickle

wheel Ø 125 mm, max. load 120 kg

Wheel diameter [mm]
Max. load at 4 km/h [kg]
48,90 €
Price / item (Ex. VAT)
Availability: 5-8 Working Days
Product description
  • Sheet steel, electrolytically zinc plated, blue passivated, Cr6 free
  • Double ball bearing in the ring bearing
  • Stable centre bolt
  • Minimum ring bearing play, smooth run, long service life due to dynamic Blickle riveting
  • Steel locking lever
  • Tyres: high quality solid rubber, hardness 80 Shore A, colour grey, non-marking, non-staining
  • Rim: high quality nylon 6 or polypropylene for the related electrically conductive product
  • High chemical resistance to many aggressive media, but not to oils
  • Temperature resistance: –20 °C to +60 °C, reduced max. load above +30 °C
Light duty swivel castor with bolt hole.
Technical data
Structureswivel castor
Modellight duty castors
Wheel materialrubber
Material of rimnylon
Type of mountingwith bolt hole
Housing materialsteel
Wheel bearingball bearing
Shore hardness80 Shore A
Swivel castor plate dimensions57 mm
Product typeswivel castors
Suppliedassembled
Wheel diameter125 mm
Max. load at 4 km/h120 kg
Overall height158 mm
Wheel width32 mm
Weight0.78 kg
Manufacturer / EU responsible Person (GPSR)
Sustainability
Sustainable product

This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.

You can find out more about product evaluation and our sustainability initiative on our information page .
Scoring System
3.6/5.9Overall score
CriteriaWeightingScore
Icon Climate protectionClimate protection30%5.9
Icon Circulatory economyCirculatory economy30%2.0
Icon BiodiversityBiodiversity25%2.0
Icon Economic efficiencyEconomic efficiency10%0.0
Icon InnovationInnovation5%3.9
More about our sustainability approach.
‌
‌
‌
