Ref.: 568274 10

PU tyre, red on nylon rim – eurokraft basic wheel Ø x width 100 x 32 mm, 2+ items

PU tyre, red on nylon rim – eurokraft basic

fixed castor

Structure
18,95 €
Price / item (Ex. VAT)
Total (Ex. VAT)
37,90 €
Availability: 5-8 Working Days
Product description
  • Quiet running
  • Does not damage floors, non-marking
  • Largely resistant against many thinned oils, greases, and chemicals
  • Hardness 95 Shore A
  • Temperature resistant from –40 °C to +80 °C
Sheet steel housing, electrolytically zinc plated in blue. Swivel bearing with dual turntable bearing. Ball bearing.
Low rolling resistance
Low rolling resistance
Non-marking
Non-marking
Technical data
Wheel diameter100 mm
Wheel materialpolyurethane (PU)
Material of rimnylon
Type of mountingwith top plate
Housing materialsteel
Max. load at 4 km/h150 kg
Wheel width32 mm
Overall height128 mm
Wheel bearingball bearing
Temperature resistance–40 °C to +80 °C
Screw hole diameter8 mm
Hub length40 mm
Hub bore8 mm
Modeltransport castors
Fixed castor plate dimensions105 x 80 mm
Swivel castor plate dimensions105 x 80 mm
Screw hole spacing80/77 x 60 mm
Housing surfacezinc plated by galvanization
Shore hardness95 A
Suppliedassembled
Structurefixed castor
Product typefixed castors
Weight0.537 kg
