Mobile and lowerable workbench, Series 8000 frame construction – eurokraft pro 3 drawers, 1 door

Solid beech worktop, 40 mm thick. Surface protection provided by environmentally friendly Danish oil. Worktop depth 700 mm.
System base frame as 4 leg welded frame with two pairs of frame feet made of profiled steel tubing (45 x 45 x 2 mm) incl. cross braces (top and bottom). Powder coated in light grey RAL 7035. Frame feet at bottom with end element incl. non-slip stud for a stable footing. Wheeled base installed on the bottom with eccentric lever (right). Operation of the eccentric lever only possible up to a max. load of 300 kg. The wheeled base can be retracted and extended using the eccentric lever. Wheeled base with 2 fixed and 2 swivel castors (castor diameter 100 mm, overall height 125 mm, tread made of thermoplastic rubber (non-marking, 85° shore), wheel body made of polypropylene). Fixed castors are installed on the left side, swivel castors on the right side (secured using wheel plate). Bar handle/push handle (enclosed loose). Powder coating. Max. distributed load 1250 kg (or max. 450 kg when the wheeled base is extended). Delivered fully assembled.

Drawers on smooth running roller guides, 90% extension, max. load 100 kg. Internal WxD 491 x 560 mm. Hinged door with self-closing spring hinges. Opening angle 180°. Aluminium grip rail with coloured strips and labelling strips. Base container with central locking. WxD 580 x 650 mm.
