Ref.: 649486 10

Platform truck with electric drive – eurokraft pro 1 mesh end panel

Platform truck with electric drive – eurokraft pro

LxWxH 1570 x 800 x 1300 mm

Platform length [mm]
Preferred RAL colour*
*Colours shown in the product image may vary.
3.400,00 €
Price / item (Ex. VAT)
Availability: 5-6 weeks
Product description
  • Highly versatile use due to modular design
  • Load remains on the trolley even on light gradients due to the mesh end panel
  • The replaceable, rechargeable battery system allows unlimited operating time
  • Intuitive operation, perfect steering control
  • Drawbar head with precise speed control, creep speed button, belly switch and horn
  • Integrated foot protection on the e-module
The electric module is easy to retrofit to equip platform trolleys with an electric drive. Complete with powerful lithium ion rechargeable battery and battery charger. Wireless – the control panel controls the drive via Bluetooth.

Easy assembly: highly versatile modular design
Drive battery: replaceable lithium-ion battery
Charging status: indicated visually and acoustically by a battery level indicator
Full mobility: up to 8 h of operation with one battery charge
Replaceable battery system: simply replace the drained battery with a fully charged one to ensure continuous operation
Pairing: via Bluetooth, wireless, fleet operation possible
Charging time: 6 h until fully charged

Easy navigation
Fatigue-free operation: due to ergonomically shaped, multifunctional drawbar head
Easy steering: due to sturdy tubular handles
Infinitely adjustable speed control: using two thumb keys (maximum speed is 4 km/h)
Creep speed: can be activated as required, for high precision forward and reverse motion
Warning function: horn on drawbar head
Safety belly switch: prevents entrapment when reversing
Integrated foot protection: prevents being caught under the drive unit
For everyone: no certificate of competence (driver's licence) required
Protection against theft: access control by means of lock
All specified max. loads apply with uniform load distribution.
Available in almost any RAL colour. Surcharge of just 10%. Custom colours are manufactured to individual customer specifications and are therefore excluded from the right of cancellation and return.
Technical data
Max. load500 kg
Fittings1 end panel
Wheel typesolid rubber / polyurethane
Loading height285 mm
Height1300 mm
Frame colourlight blue RAL 5012
Wheel diameter200 / 230 mm
Wheel bearingroller bearing
Wheel fittings2 swivel castors with brakes, 2 drive wheels
Platform colourblack
Platform materialplastic
Frame materialsteel
Panel height500 mm
Side panel materialsteel mesh
Mesh size50 x 50 mm
Battery capacity12 Ah
Mains voltageAC 100 – 240 V
Charging time6 hrs
Power0.25 kW
Voltage24 V
Max. speed5 km/h
Product typeplatform trucks with electric drive
Suppliedpartially assembled
Platform length1210 mm
Platform width800 mm
Length1570 mm
Width800 mm
Weight70 kg
Manufacturer / EU responsible Person (GPSR)
Sustainability
Sustainable product

This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.

You can find out more about product evaluation and our sustainability initiative on our information page .

Product CO₂ footprint

LCA functional unit
1
Recycled content in %?
0
CO2 footprint year of calculation
2026
LCA validity (in years)
1
CO2 footprint calculation method product
Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
CO2 footprint system boundaries
Cradle-to-gate

PCF Lifecycle Breakdown

607.83kg CO₂e
LCA Raw Material Extraction & Processing
70.3%
LCA packaging production
0.9%
LCA Product Manufacturing
24.4%
LCA Inbound and Outbound Transportation
4.4%
Scoring System
3.4/5.9Overall score
CriteriaWeightingScore
Icon Climate protectionClimate protection30%3.5
Icon Circulatory economyCirculatory economy30%4.1
Icon BiodiversityBiodiversity25%1.0
Icon Economic efficiencyEconomic efficiency10%1.0
Icon InnovationInnovation5%3.9
