C+P – ACURADO universal cupboard WxD 500 x 500 mm
light grey / ruby red
- Durable steel construction, stove enamelled body
- Max. load 70 kg per coated shelf
- 110° door opening angle
- ERGO LOCK recessed handle lock (3 bolt lock), incl. 2 keys (individual key)
- With plastic glides as standard (floor protection)
- Cupboard doors reinforced in the middle
- Shelves adjustable in 15 mm grid
This KAISER+KRAFT label distinguishes products that meet particularly sustainable criteria
Safety tested
This is a test symbol. GS stands for certified safety.
This is a test symbol. GS stands for certified safety.
Planning service
Ref.: 488798 10
Properties
Body colour: light grey RAL 7035, Door colour: ruby red RAL 3003
Good reasons to purchase products from us
- Worldwide delivery
- Perfect service
- Individual offers
- Fast delivery
We will be happy to help you
export@kaiserkraft.com
Monday to Friday from 8.00 am to 4.00 pm CET
Product description
ACURADO steel double door cupboard, reinforced door for high stability, doors hinged at top and bottom in pivot pins with an opening angle of approx. 110°, hinged on right, 4 painted shelves, ergonomic ergo-lock recessed handle for optimum operating safety and wear resistance, 3 bolt lock, with cylinder lock and 2 keys.
Also available with PIN code locks upon request.
Supplied fully assembled.
- Durable steel construction, stove enamelled body
- Max. load 70 kg per coated shelf
- 110° door opening angle
- ERGO LOCK recessed handle lock (3 bolt lock), incl. 2 keys (individual key)
- With plastic glides as standard (floor protection)
- Cupboard doors reinforced in the middle
- Shelves adjustable in 15 mm grid
This KAISER+KRAFT label distinguishes products that meet particularly sustainable criteria
Safety tested
This is a test symbol. GS stands for certified safety.
This is a test symbol. GS stands for certified safety.
Planning service
Technical data
| Width | 500 mm |
|---|---|
| Height | 1950 mm |
| Depth | 500 mm |
| Material | steel, stove enamelled |
| Product type | double door cupboards |
| Door type | hinged door |
| Number of doors | 1 pcs. |
| Number of shelves | 4 pcs. |
| Shelf material | sheet steel |
| Shelf colour | light grey RAL 7035 |
| Max. shelf load | 70 kg |
| Feature | lockable |
| Lock type | ergo lock, cylinder lock, three-bolt |
| Number of lever arch file heights | 5 pcs. |
| Internal fittings | 4 shelves |
| Shelf height adjustment increments | 15 mm |
| Plinth height | 100 mm |
| Opening angle of doors | 110 ° |
| Shelf thickness | 24 mm |
| Thickness of body | 0.88 mm |
| Door thickness | 25 mm |
| Thickness of rear panel | 0.75 mm |
| Door hinge position | right |
| Max. cupboard load | 450 kg |
| Locks | triple |
| Weight | 43.77 kg |
| Supplied | assembled |
