Ref.: 847163 10

Electric barrier – Mannus with spring loaded pendulum support, W 324 mm

Electric barrier – Mannus

barrier beam length 2.5 m

Barrier beam length [m]
New
on request
Price / item (Ex. VAT)
Availability: 3-4 weeks
Product description
  • Versatile with boom lengths from 2.5 to 6.2 m
  • Plug and Play – immediate use with 2-channel remote control
  • Energy-efficient through 24 V technology with 230 V connection
  • Automatic reversal upon obstacle contact
  • Robust steel housing in striking RAL 1028 (yellow)
Robust, efficient and versatile: Our electric barrier with barrier beam lengths of 2.5 to 6.2 metres (from the housing) is the ideal solution for demanding access controls in intensive operation. Thanks to a 230-volt connection with economical 24-volt technology, automatic reversal upon obstacle contact, soft-stop function and factory-installed accessories, it offers maximum safety and comfort – including emergency release, two safety circuits, timed closing and potential-free command inputs. The colour-coated steel housing in RAL 1028 (yellow), the high-quality barrier beam made of aluminium with reflective strips, as well as the height-adjustable pendulum support make it a durable and reliable choice for any entrance – delivery on pallet including handheld transmitter, installation upon request.

Mounting type: For bolting down
Operating modes: Automatic or dead man's switch operation
Safety functions: 2 safety circuits, timed closing, potential-free command inputs
Integrated features: Built-in socket
Opening times and consumption:
2.5 sec. at 4.0 m (120 W)
3.0 sec. at 5.0 m (120 W)
8.0 sec. at 6.0 m (200 W)
Barrier beam:
Up to 5.0 m: Aluminium 60 x 40 mm with edge protection
From 5.5 m: Aluminium 100 x 40 mm
Colour: RAL 9010 (white) with red reflective strips
Support post:
Standard: Height-adjustable, sprung pendulum support
Optional: Fixed support post
Technical data
Height above ground1008 mm
Width324 mm
Materialsteel
Colourmelon yellow RAL 1028
Type of mountingfor bolting in place
Uprightswith spring loaded pendulum support
Modelfor bolting in place
Lock typeprofile cylinder
Method of operationelectric
Base plate length320 mm
Base plate width222 mm
Base plate height10 mm
Product typeboom gates
Suppliedflat pack
Barrier beam length2.50 m
Barrier clearance length2500 mm
Weight60 kg
