Ref.: 903532 10

90° curve – Gura aluminium frame, plastic skate wheels, track width 500 mm

90° curve – Gura
90° curve – Gura, aluminium frame, plastic skate wheels, track width 500 mm, axle spacing 100 mm-0
90° curve – Gura (Product illustration 2)-1
90° curve – Gura (Product illustration 3)-2
90° curve – Gura (Product illustration 4)-3

axle spacing 100 mm

Axle spacing [mm]
619,00 €
Price / item (Ex. VAT)
Availability: 3-4 weeks
Product description
  • Modular system facilitates rapid material flow
  • High quality workmanship
  • Ideal supplement in a conveyor system
Sturdy lateral zinc plated steel profiles, 20 x 60 x 20 mm. Ball bearing steel or plastic skate wheels, Ø 48 mm. Staggered layout of skate wheels from axle to axle with same quantity of skate wheels per axle.
Base surface of the goods to be transported has to be flat, firm and smooth.

Static maximum load 200 kg per metre of track with supports spaced 1 m apart.

Designing your conveyor
Build up the required conveyor length from individual sections. Determine required number of straight and curved sections. Determine track width by largest dimension of goods to be transported. Determine spacing between axles by smallest dimension of goods to be transported.
With 75 mm axle spacing the effective length for 1 m = 975 mm, for 2 m = 1950 mm.

Suitable for use in closed, dry rooms with, occasional relocation.
Special designs, 45° curves and passages available on request.
Two-legged supports and side guide rails can be found under combinations and accessories.
Planning service
Planning service
Technical data
Track width500 mm
Overall height69 mm
Materialplastic
Radius of curve800 mm
Roller diameter48 mm
Width540 mm
Design of framealuminium
Max. load with 1 m frame support spacing200 kg
Skate wheel arrangement5 : 5
Width of goods conveyed150 – 600 mm
Coloursilver blue
Product typelight duty skate wheel conveyors
Suppliedassembled
Axle spacing100 mm
Length of goods conveyed300 – 1000 mm
Weight14.1 kg
