PU tyres, puncture proof wheel Ø x width 210 x 65 mm
fixed castor with roller bearings
- Puncture proof
- The reliable alternative to pneumatic tyres
- Non-marking
Low rolling resistance
Non-marking
Ref.: 485385 10
Properties
Structure: fixed castor, Wheel bearing: roller bearing, Weight [kg]: 2.24
Only 3 available
Good reasons to purchase products from us
- Worldwide delivery
- Perfect service
- Individual offers
- Fast delivery
We will be happy to help you
export@kaiserkraft.com
Monday to Friday from 8.00 am to 4.00 pm CET
Product description
Sheet steel housing, bright zinc plated, with dual ball bearings in live ring, splash water protection. On swivel castors, central bolts are secured with nut and lock washer.
On request
– Various wheel sets
– Spoke wheels
– Grey tyres
– Various wheel sets
– Spoke wheels
– Grey tyres
- Puncture proof
- The reliable alternative to pneumatic tyres
- Non-marking
Low rolling resistance
Non-marking
Technical data
| Wheel diameter | 210 mm |
|---|---|
| Wheel material | polyurethane (PU) |
| Material of rim | sheet steel, powder coated |
| Housing material | steel |
| Max. load at 4 km/h | 100 kg |
| Type of mounting | with top plate |
| Wheel width | 65 mm |
| Overall height | 245 mm |
| Temperature resistance | –40 °C to +40 °C |
| Screw hole diameter | 11 mm |
| Hub length | 75 mm |
| Hub bore | 20 mm |
| Fixed castor plate dimensions | 135 x 114 mm |
| Swivel castor plate dimensions | 135 x 110 mm |
| Screw hole spacing | 105 x 80 mm |
| Housing surface | zinc plated |
| Shore hardness | 83 A |
| Product type | castors, puncture proof |
| Feature | does not damage floors low rolling resistance non-marking |
| Supplied | assembled |
