Ref.: 485385 10

PU tyres, puncture proof wheel Ø x width 210 x 65 mm

PU tyres, puncture proof

fixed castor with roller bearings

Structure
Product type
76,90 €
Price / item (Ex. VAT)
Availability: 3-4 weeks
Product description
  • Puncture proof
  • The reliable alternative to pneumatic tyres
  • Non-marking
Sheet steel housing, bright zinc plated, with dual ball bearings in live ring, splash water protection. On swivel castors, central bolts are secured with nut and lock washer.
On request
– Various wheel sets
– Spoke wheels
– Grey tyres
Low rolling resistance
Low rolling resistance
Non-marking
Non-marking
Technical data
Wheel diameter210 mm
Wheel materialpolyurethane (PU)
Material of rimsheet steel, powder coated
Type of mountingwith top plate
Housing materialsteel
Max. load at 4 km/h100 kg
Wheel width65 mm
Overall height245 mm
Temperature resistance–40 °C to +40 °C
Screw hole diameter11 mm
Hub length75 mm
Hub bore20 mm
Fixed castor plate dimensions135 x 114 mm
Swivel castor plate dimensions135 x 110 mm
Screw hole spacing105 x 80 mm
Housing surfacezinc plated
Shore hardness83 A
Featuredoes not damage floors low rolling resistance puncture proof non-marking
Suppliedassembled
Structurefixed castor
Wheel bearingroller bearing
Product typefixed castors
Weight2.24 kg
