Elastic tyre on nylon rim wheel Ø x width 160 x 46 mm
- Compatible with all floors, non-marking, quiet, smooth running
- High max. load, popular for use in the event sector
- Hardness 65 Shore A
- Temperature resistant from –20 °C to +80 °C
Non-marking
Low rolling resistance
High maximum load
Ref.: 568414 10
Elastic tyre on nylon rim, wheel Ø x width 160 x 46 mm, fixed castor
Properties
Structure: fixed castor, Weight [kg]: 1.76
Good reasons to purchase products from us
- Worldwide delivery
- Perfect service
- Individual offers
- Fast delivery
We will be happy to help you
export@kaiserkraft.com
Monday to Friday from 8.00 am to 4.00 pm CET
Product description
Sheet steel housing, electrolytically zinc plated in blue. Small plastic thread guard. Ball bearings.
- Compatible with all floors, non-marking, quiet, smooth running
- High max. load, popular for use in the event sector
- Hardness 65 Shore A
- Temperature resistant from –20 °C to +80 °C
Non-marking
Low rolling resistance
High maximum load
Technical data
| Supplied | assembled |
|---|---|
| Overall height | 195 mm |
| Type of mounting | with top plate |
| Material of rim | nylon |
| Housing material | steel |
| Housing surface | zinc plated by galvanization |
| Hub bore | 12 mm |
| Hub length | 59 mm |
| Fixed castor plate dimensions | 135 x 110 mm |
| Swivel castor plate dimensions | 135 x 110 mm |
| Product type | transport castors |
| Wheel width | 46 mm |
| Wheel diameter | 160 mm |
| Wheel bearing | double ball bearing |
| Wheel material | rubber – solid rubber – elastic |
| Screw hole spacing | 105 x 84/76 mm |
| Screw hole diameter | 12 mm |
| Shore hardness | 65 A |
| Temperature resistance | –20 °C to +80 °C |
| Max. load at 4 km/h | 300 kg |
